Each instruction has a one-byte (8-bit) operation codes or opcode. With 8- bit binary opcode, a total of different operation codes can. Intel instruction set. x0, x1, x2, x3, x4, x5, x6, x7, x8, x9, xA, xB, xC, xD, xE, xF. 0x, NOP 1 4 , LXI B,d16 3 10 , STAX B 1 7 , INX B 1 6 –K 1 1 ADDRESSING MODES OF Shown in the following are the sizes of a 5CH This can be verified from the opcode chart given in the previous chapter.
